gNodeBs

A quick summary of G Node Bs

Available gNodeBs

GNodeBs (gNBs) are the 5G wireless base stations that transmit and receive communications between the user equipment and the mobile network.

AW2S


  • Configuration: RRH 4x4 Frequency Band N78 3400-3800MHz
  • Mode: TDD Operating BW up to 100MHz
  • Power per antenna: >=2W Power supply -48V
  • Interface CPRI
  • Control and Management ORI

RRU unit is connected through fiber (CPRI) to 1 gNodeB composed of :

  • X86 server
  • AW2S PCIe to CPRI interface board
  • AW2S Drivers for RRU Control and management
  • Amarisoft 5G stack software and Core *

AMARI Callbox Classic.

  • Allows for multiple cells configuration.
  • Supports both 5G NR NSA and SA mode.
  • 3 2x2 MIMO SDRs
  • UL/DL: 600/150 Mbps
  • LTE and NB-Iot Capable
  • Internal use |

Amari Call Box 1
Amari Call Box 3

LimeNET 5G CrowdCell

  • Allows for multiple cells configuration.
  • Supports 5G NR SA mode
  • 2 2x2 MIMO SDRs
  • 4 antennas
  • Power amplifier
  • External use

Limenet Crowd Cell

LimeNET

  • Allows for multiple cells configuration.
  • Supports LTE and NB-IoT
  • 2x2 MIMO SDR (PCI)
  • 4 antennas
  • External use

Limenet

LimeNET Mini

  • Allows for multiple cells configuration.
  • Supports LTE and NB-IoT
  • 2x2 MIMO SDR (USB)
  • 4 antennas
  • Internal use (mainly for NB-IoT)

Limenet Mini

ETUS N310

  • SDR
  • 4X4 MIMO
  • Up to 100MHz BW

Etus N 310

ETUS B210

  • SDR
  • 2X2 MIMO
  • Up to 56MHz BW

Etus B 210
